Figures¶
Images with captions are created with the figure directive in both, MyST Parser’s Markdown, and docutil’s reStructureText.
Figure directive¶
The figure directive has one mandatory argument, the image URI, several optional arguments, the figure’s caption and the figure’s legend.
Take a look at the official documentation of docutils or MyST Parser to know more about the directive and their available arguments. The documentation of Nefertiti for Sphinx shows examples of the most frequent combination of arguments.
One particular detail of Nefertiti for Sphinx is that when the figure receives either a scale, a width or height the total width of the generated HTML figure element is adapted to the calculated width of the image displayed in the figure. This is done via the JavaScript plugin. The consequence is that caption’s and legend’s width is reduced to match the width of the image.
Tip
It is not recommend to use width or height in combination with scale, as the resulting image does not maintain the original aspect ratio.
A sample figure¶
An example of a figure without optional arguments (no change of dimensions, no change of alignment), makes the image cover the available width, displaying the caption and the legend centered below the image:
```{figure} img/Watercolour_by_Mong_kyaw_sing_marma.jpg
This is the caption of the figure.
This is considered the legend of the figure.
And this is also part of the legend.
```
.. figure:: img/Watercolour_by_Mong_kyaw_sing_marma.jpg
This is the caption of the figure.
This is considered the legend of the figure.
And this is also part of the legend.
This is the caption of the figure.¶
This is considered the legend of the figure.
And this is also part of the legend.
Figure dimensions¶
To adapt figure’s size you can provide either the width or height and the other dimension will adapt to keep the aspect ratio. Alternatively you can pass the scale argument followed by an integer from 0 to 100 representing the percentage with respect to the width of the main documentation area.
Setting figure’s width¶
The following example displays a figure at half of its width, and aligned to the center. The width dimension can be expressed in the following units: em, ex, px, in, cm, mm, pt, pc, %.
```{figure} img/Watercolour_by_Mong_kyaw_sing_marma.jpg
:alt: Watercolour painting by Mong kyaw sing marma
:width: 50%
:align: center
Watercolor painting by *Mong kyaw sing marma*.
```
.. figure:: img/Watercolour_by_Mong_kyaw_sing_marma.jpg
:alt: Watercolour painting by Mong kyaw sing marma
:width: 50%
:align: center
Watercolor painting by **Mong kyaw sing marma**.
Watercolor painting by Mong kyaw sing marma.¶
Setting figure’s height¶
The following example displays an image centered and with a height of 500px. The original height dimension is 600px. The height dimension can be expressed in the following units: em, ex, px, in, cm, mm, pt, pc, but not in percentage.
```{figure} /landscape-nature-trees-house-sunset-painting.jpg
:alt: Landscape nature trees house sunset painting
:height: 500px
:align: center
Unknown author.
Source: [pxhere.com](https://pxhere.com/en/photo/1603256>).
CC0 Public Domain. Free for personal and commercial use.
No attribution required.
```
.. figure:: /landscape-nature-trees-house-sunset-painting.jpg
:alt: Landscape nature trees house sunset painting
:height: 500px
:align: center
Unknown author.
Source: `pxhere.com <https://pxhere.com/en/photo/1603256>`_.
CC0 Public Domain. Free for personal and commercial use.
No attribution required.
Unknown author. Source: pxhere.com. CC0 Public Domain. Free for personal and commercial use. No attribution required.¶
Figure aligment¶
The previous examples show how to display figures scaled and centered. Alignment with the figure directive works just like with the image directive. When the figure is aligned to the center, it acts as a block and text can not surround the image, however when the alignment is left or right the text will surround the image.
Figure left aligned¶
```{figure} img/Watercolour_by_Mong_kyaw_sing_marma.jpg
:alt: Watercolour painting by Mong kyaw sing marma
:width: 50%
:align: left
Watercolor painting by **Mong kyaw sing marma**.
Source: `Wikimedia Commons`_. Licensed under the Creative Commons
Attribution-Share Alike 4 International.
```
Nunc accumsan enim ac rutrum dignissim. In sed erat urna. In turpis
erat, iaculis non nibh nec, suscipit convallis ante. Fusce
ullamcorper magna semper libero laoreet, sed faucibus ligula
venenatis. Nunc justo leo, faucibus at turpis eget, dapibus
pharetra tortor.
Morbi commodo ut quam eget ultricies. Nam porta condimentum erat,
in vehicula dui congue vitae. Cras fringilla faucibus faucibus.
Phasellus vitae efficitur arcu. Sed mollis elementum nisl, ac
mattis ex feugiat vitae. Donec augue lectus, viverra molestie mi
nec, volutpat auctor purus. Duis viverra, ante quis lobortis
fermentum, lectus tortor fermentum justo, a finibus lectus
ipsum a leo. Nunc ultrices sapien mi, et tempor risus vestibulum
vel. Cras egestas diam vel massa vestibulum, ut faucibus elit porta.
.. figure:: img/Watercolour_by_Mong_kyaw_sing_marma.jpg
:alt: Watercolour painting by Mong kyaw sing marma
:width: 50%
:align: left
Watercolor painting by **Mong kyaw sing marma**.
Source: `Wikimedia Commons`_. Licensed under the Creative Commons
Attribution-Share Alike 4 International.
Nunc accumsan enim ac rutrum dignissim. In sed erat urna. In turpis
erat, iaculis non nibh nec, suscipit convallis ante. Fusce
ullamcorper magna semper libero laoreet, sed faucibus ligula
venenatis. Nunc justo leo, faucibus at turpis eget, dapibus pharetra tortor.
Morbi commodo ut quam eget ultricies. Nam porta condimentum erat,
in vehicula dui congue vitae. Cras fringilla faucibus faucibus.
Phasellus vitae efficitur arcu. Sed mollis elementum nisl, ac
mattis ex feugiat vitae. Donec augue lectus, viverra molestie mi
nec, volutpat auctor purus. Duis viverra, ante quis lobortis
fermentum, lectus tortor fermentum justo, a finibus lectus ipsum
a leo. Nunc ultrices sapien mi, et tempor risus vestibulum vel.
Cras egestas diam vel massa vestibulum, ut faucibus elit porta.
Watercolor painting by Mong kyaw sing marma.
Source: Wikimedia Commons_. Licensed under the Creative Commons
Attribution-Share Alike 4 International.¶
Nunc accumsan enim ac rutrum dignissim. In sed erat urna. In turpis erat, iaculis non nibh nec, suscipit convallis ante. Fusce ullamcorper magna semper libero laoreet, sed faucibus ligula venenatis. Nunc justo leo, faucibus at turpis eget, dapibus pharetra tortor.
Morbi commodo ut quam eget ultricies. Nam porta condimentum erat, in vehicula dui congue vitae. Cras fringilla faucibus faucibus. Phasellus vitae efficitur arcu. Sed mollis elementum nisl, ac mattis ex feugiat vitae. Donec augue lectus, viverra molestie mi nec, volutpat auctor purus. Duis viverra, ante quis lobortis fermentum, lectus tortor fermentum justo, a finibus lectus ipsum a leo. Nunc ultrices sapien mi, et tempor risus vestibulum vel. Cras egestas diam vel massa vestibulum, ut faucibus elit porta.
Figure right aligned¶
```{figure} img/Watercolour_by_Mong_kyaw_sing_marma.jpg
:alt: Watercolour painting by Mong kyaw sing marma
:width: 50%
:align: right
Watercolor painting by **Mong kyaw sing marma**.
Source: `Wikimedia Commons`_. Licensed under the Creative Commons
Attribution-Share Alike 4 International.
```
Nunc accumsan enim ac rutrum dignissim. In sed erat urna. In turpis
erat, iaculis non nibh nec, suscipit convallis ante. Fusce
ullamcorper magna semper libero laoreet, sed faucibus ligula
venenatis. Nunc justo leo, faucibus at turpis eget, dapibus
pharetra tortor.
Morbi commodo ut quam eget ultricies. Nam porta condimentum erat,
in vehicula dui congue vitae. Cras fringilla faucibus faucibus.
Phasellus vitae efficitur arcu. Sed mollis elementum nisl, ac
mattis ex feugiat vitae. Donec augue lectus, viverra molestie mi
nec, volutpat auctor purus. Duis viverra, ante quis lobortis
fermentum, lectus tortor fermentum justo, a finibus lectus
ipsum a leo. Nunc ultrices sapien mi, et tempor risus vestibulum
vel. Cras egestas diam vel massa vestibulum, ut faucibus elit porta.
.. figure:: img/Watercolour_by_Mong_kyaw_sing_marma.jpg
:alt: Watercolour painting by Mong kyaw sing marma
:width: 50%
:align: right
Watercolor painting by **Mong kyaw sing marma**.
Source: `Wikimedia Commons`_. Licensed under the Creative Commons
Attribution-Share Alike 4 International.
Nunc accumsan enim ac rutrum dignissim. In sed erat urna. In turpis
erat, iaculis non nibh nec, suscipit convallis ante. Fusce
ullamcorper magna semper libero laoreet, sed faucibus ligula
venenatis. Nunc justo leo, faucibus at turpis eget, dapibus
pharetra tortor.
Morbi commodo ut quam eget ultricies. Nam porta condimentum erat,
in vehicula dui congue vitae. Cras fringilla faucibus faucibus.
Phasellus vitae efficitur arcu. Sed mollis elementum nisl, ac
mattis ex feugiat vitae. Donec augue lectus, viverra molestie mi
nec, volutpat auctor purus. Duis viverra, ante quis lobortis
fermentum, lectus tortor fermentum justo, a finibus lectus
ipsum a leo. Nunc ultrices sapien mi, et tempor risus vestibulum
vel. Cras egestas diam vel massa vestibulum, ut faucibus elit porta.
Watercolor painting by Mong kyaw sing marma.
Source: Wikimedia Commons_. Licensed under the Creative Commons
Attribution-Share Alike 4 International.¶
Nunc accumsan enim ac rutrum dignissim. In sed erat urna. In turpis erat, iaculis non nibh nec, suscipit convallis ante. Fusce ullamcorper magna semper libero laoreet, sed faucibus ligula venenatis. Nunc justo leo, faucibus at turpis eget, dapibus pharetra tortor.
Morbi commodo ut quam eget ultricies. Nam porta condimentum erat, in vehicula dui congue vitae. Cras fringilla faucibus faucibus. Phasellus vitae efficitur arcu. Sed mollis elementum nisl, ac mattis ex feugiat vitae. Donec augue lectus, viverra molestie mi nec, volutpat auctor purus. Duis viverra, ante quis lobortis fermentum, lectus tortor fermentum justo, a finibus lectus ipsum a leo. Nunc ultrices sapien mi, et tempor risus vestibulum vel. Cras egestas diam vel massa vestibulum, ut faucibus elit porta.
